| Brand Name: | Soeteck |
| Model Number: | 40ft Immersion |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 30-45 working days |
| Payment Terms: | D/A |
AI training clusters have outgrown the rack. A single container is now expected to carry megawatt-class load, and air cooling cannot move that much heat out of a sealed steel shell without fans, a raised floor and a plant room — three things a mining site, a desert pad or a remote industrial yard rarely has room to build.
The 1.2 MW Single-Phase Immersion Container Data Center answers that with a 40ft High Cube shell built around 12 immersion tanks. Each tank is rated for up to 100 kW, so one container delivers 1.2 MW of total capacity inside a single 12192 x 2438 x 2896 mm unit that leaves the factory fully integrated.
Inside, servers and GPU nodes are completely submerged in a non-conductive dielectric fluid. The fluid lifts heat directly off the components, and the integrated fluid distribution unit rejects it outside the shell. With no server fans, no raised floor and no airflow path to balance, the container stays silent, dust-proof and sealed against humidity — which is exactly what makes single-phase immersion cooling deployable at remote edges and harsh industrial sites where a conventional computer room cannot be built at all.
| Model | Cooling Architecture | Rack / Tank Count | Max Power Density | Total Capacity | Container Type | Dimensions (L*W*H) |
|---|---|---|---|---|---|---|
| 20ft Immersion › | Single-Phase Immersion (Integrated FDU) |
4 Tanks | 100 kW / Tank | 400 kW | 20ft High Cube | 6058 x 2438 x 2896 mm |
| 40ft Immersion › | Single-Phase Immersion (Integrated FDU) |
12 Tanks | 100 kW / Tank | 1.2 MW | 40ft High Cube | 12192 x 2438 x 2896 mm |
| 40ft Cold Plate (In-Row) › | In-Row CDU (Liquid-to-Liquid / Air Assist) |
12 Racks (Space for CDUs) |
60 kW / Rack | 720 kW | 40ft High Cube | 12192 x 2438 x 2896 mm |
| 40ft Cold Plate (Rack) › | Rack-Mounted CDU (Distributed Manifold) |
14 Racks (Maximized Space) |
50 kW / Rack | 700 kW | 40ft High Cube | 12192 x 2438 x 2896 mm |
| 20ft Cold Plate (Rack) › | Rack-Mounted CDU (Distributed Manifold) |
5 Racks | 50 kW / Rack | 250 kW | 20ft High Cube | 6058 x 2438 x 2896 mm |
Instead of pushing air across a cold plate, this 40ft container submerges the IT hardware in a non-conductive dielectric fluid, so heat leaves the components directly into the liquid and is rejected through the integrated fluid distribution unit. No server fans, no in-row air handlers and no compressor-driven cooling remain in the loop — the overhead a conventional air-cooled container spends on moving heat is simply removed from the design.
Each of the 12 immersion tanks is rated for up to 100 kW, which brings a single 40ft High Cube shell to 1.2 MW of total capacity. The sealed dielectric bath also removes fan-induced vibration and keeps junction temperatures steady for high-TDP AI processors, so GPU hardware runs at sustained boost clocks and stays clear of the dust and humidity that shorten its service life in rugged containerized environments.
Focus on the core cooling demands of high-density data center deployments, where our full range of premium products leverages advanced technological advantages to reliably safeguard continuous, efficient, and stable operation.
5-30 kW per Cabinet
Airtight cold aisle enclosure, 90%+ cold air utilization rate, PUE ≤ 1.2, fast deployment and flexible expansion for medium-density IT loads.
10-80 kW Total Power
Prefabricated all-in-one design, anti-vibration & dust-proof, plug-and-play, ideal for edge computing and temporary computing demand scenarios.
30-100 kW per Cabinet
Hybrid air-liquid cooling, direct heat dissipation from GPU/CPU, AI-ready design, high power density with low energy consumption.
50-200 kW per Cabinet
Immersion cooling with dielectric fluid, 100x higher heat dissipation efficiency than air cooling, PUE ≤ 1.1, perfect for ultra-high density AI clusters.
Empowering next-generation infrastructure with superior thermal management for high-wattage computing demands.
