| Brand Name: | Soeteck |
| Model Number: | SY-NCB60637W |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 30-45 working days |
| Payment Terms: | D/A |
The Soeteck SY-NCB60637W server rack cabinet is a 37U enclosure measuring 600 x 600 x 1833 mm, built to carry up to 1200 kg of 19-inch equipment in an office-side network room. A tempered glass door in a silver-grey steel frame keeps the front closed while leaving switch and server status visible, which is what most network rooms actually need from a cabinet.
The frame is cold-rolled steel with quick-release side panels and a quick-release rear door, so cabling is reached from either side or from the back without tools. Knock-out cable entries in the top and bottom plates take the cable path out of the rack, adjustable 19-inch mounting columns accommodate different equipment depths, and the base rolls on castors with four levelling feet to take the final load off the wheels.
| Model No. | Width (mm) | Depth (mm) | Height (mm) | Capacity (U) | Load Bearing |
|---|---|---|---|---|---|
| SY-NCB60637W › | 600 | 600 | 1833 | 37U | 1200 KG |
| SY-NCB60842W › | 600 | 800 | 2055 | 42U | 1200 KG |
| SY-NCB81042W › | 800 | 1000 | 2055 | 42U | 1200 KG |
| SY-NCB81247W › | 800 | 1200 | 2277 | 47U | 1200 KG |
The front of the SY-NCB60637W is a full-height tempered glass door in a silver-grey steel frame, so switch LEDs, port activity and equipment status are visible without opening anything. The 600 mm wide, 1833 mm tall enclosure holds 37U of 19-inch equipment up to 1200 kg, which is enough for a network row or a small server cluster in an office-side room.
Side panels and the rear steel door come off with quick-release latches rather than tools, so a technician reaches cabling and hardware from either side or from the back during a change. Knock-out cable entries in the top and bottom plates take the cable path out of the rack without cutting sheet metal on site, and adjustable 19-inch mounting columns set the equipment depth.
