| Brand Name: | Soeteck |
| Model Number: | Plan 4 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 30-45 working days |
| Payment Terms: | D/A |
The Soeteck Plan 4 modular data center puts fourteen 42U cabinets, a 120 kVA tower modular UPS and a tailored fan-wall air handling section inside a single 4800 × 3600 × 2000 mm skid. The suite is pre-wired and pre-piped in the factory, so the site work that remains is power, water and commissioning rather than building a room.
A sealed hot aisle captures the exhaust from all fourteen racks, and because Plan 4 replaces fixed in-row units with a fan wall, the cooling capacity is specified to the project instead of being forced to match a catalogue value. Power comes from 120 kVA tower modular UPS with hot-swappable 30 kVA modules in 3+1, and the plan scales within the same family up to 48 cabinets at up to 15 kW per rack.
| Configuration | IT Cabinets | Power / Cab | UPS System | Cooling Capacity | Refrigeration Type | Dimensions (L*W*H) |
|---|---|---|---|---|---|---|
| Plan 1 › | 12 Cabinets | 5 kW | 90K Rack Modular (15kVA modules, 4+1) |
25.5kW x 4 (3+1 Redundancy) |
In-Row AC | 4200 x 3600 x 2000 mm |
| Plan 2 › | 12 Cabinets | 5 kW | 120K Tower Modular (30kVA modules, 3+1) |
65.5kW x 2 (1+1 Redundant) |
In-Row AC | 4800 x 3600 x 2000 mm |
| Plan 3 › | 14 Cabinets | 5 kW | 120K Tower Modular (30kVA modules, 3+1) |
71.1kW x 1 (N Redundancy) |
Room-Level AC | 4800 x 3600 x 2000 mm |
| Plan 4 › | 14 Cabinets | 5 kW | 120K Tower Modular (30kVA modules, 3+1) |
Custom Capacity (Tailored) |
FAN WALL | 4800 x 3600 x 2000 mm |
| Plan 5 › | 18 Cabinets | 5 kW | Modular N+1 (25kVA modules, 4+1) |
31.1kW x 4 (3+1 Redundancy) |
In-Row AC | 6000 x 3600 x 2000 mm |
| Plan 6 › | 24 Cabinets | 5 kW | Modular N+1 (25kVA modules, 5+1) |
40.9kW x 4 (3+1 Redundancy) |
In-Row AC | 8400 x 3600 x 2000 mm |
| Custom › | ≤ 48 Cabinets | ≤ 15 kW | Max 500kVA (2N/N+1 Redundancy) |
Flexible Capacity (Row or Room) |
Air / Water / Chilled | Length ≤ 15000 mm |
Factory-Integrated Footprint: Fourteen 42U cabinets, the modular UPS and the fan-wall air handling section sit inside one 4800 × 3600 × 2000 mm skid that is pre-wired and pre-piped at the factory, leaving only site power and water connections for delivery day.
Sealed Hot Aisle: The fully enclosed hot aisle captures exhaust air from all fourteen racks, so recirculation does not erode the 5 kW-per-cabinet design load and the room can be run warmer without creating hot spots.
Tailored Fan-Wall Cooling: Plan 4 cools the aisle with a fan wall whose capacity is specified per project rather than with fixed in-row units, which is what makes it the right plan when rack loads are known but not uniform.
120 kVA Tower Modular UPS: Hot-swappable 30 kVA modules in a 3+1 arrangement protect the whole row with N+1 power, so a failed module is replaced without shutting the load down.
Tailored to diverse deployment scenarios—including small enterprise IT rooms, retrofitted traditional data centers and outdoor edge nodes—our modular data center solutions balance performance, cost and energy efficiency.
3-15 kW per Cabinet
All-in-one integrated cabinet design, plug-and-play deployment (1-3 days), remote intelligent monitoring. Ideal for edge endpoints like retail stores, ATMs and small enterprise IT rooms.
8-30 kW per Cabinet
Column-level prefabricated design, flexible expansion by rows, fits existing server rooms without major reconstruction. PUE 1.2-1.4, perfect for medium-density enterprise IT deployments.
15-40 kW per Cabinet
Airtight cold/hot aisle enclosure, 90%+ cold air utilization, PUE reduced to 1.2-1.3. Cost-effective upgrade for traditional open data centers to support high-density servers.
10-500 kW (20ft/40ft)
Prefabricated all-in-one container (20ft/40ft), dustproof/anti-vibration, deployable outdoors. Liquid cooling optional for AI high-density computing (PUE ≤1.1), ideal for edge & temporary computing needs.
Empowering next-generation infrastructure with superior thermal management for high-wattage computing demands.
