Engineered for high-performance, fast-charging backup power applications, the SOETECK SY-VRLA Series 12V AGM Battery leverages advanced fiberglass mat technology to immobilize electrolyte, delivering superior high-rate discharge capability and rapid recharge performance. Designed as a premium upgrade to gel and flooded lead-acid batteries, it meets the dynamic power demands of UPS systems, telecom base stations, RV/marine power, and solar off-grid applications.
Constructed with high-purity lead-calcium alloy grids and vacuum-sealed AGM technology, it eliminates acid leakage and stratification, supporting any mounting orientation (vertical/horizontal). With a deep-cycle life of up to 800 cycles (80% DOD) and low self-discharge rate (<3%/month at 25°C), it is a maintenance-free, robust power solution for both cyclic discharge and standby power scenarios requiring fast energy recovery.
| Models | Nominal Voltage | Rated Capacity | Length (mm) | Width (mm) | Height (mm) | Total Height (mm) | Appox.Weight (kg) |
|---|---|---|---|---|---|---|---|
| SY-GFM12005 › | 12V | 5Ah (20hrs/25℃) | 90 | 70 | 101 | 107 | 1.50 |
| SY-GFM12007 › | 12V | 7Ah (10hrs/25℃) | 151 | 65 | 94 | 100 | 1.97 |
| SY-GFM12009 › | 12V | 9Ah (10hrs/25℃) | 151 | 65 | 94 | 100 | 2.50 |
| SY-GFM12012 › | 12V | 12Ah (10hrs/25℃) | 151 | 98 | 95 | 101 | 3.30 |
| SY-GFM12017 › | 12V | 17Ah (10hrs/25℃) | 180 | 77 | 167 | 167 | 4.80 |
| SY-GFM12020 › | 12V | 20Ah (10hrs/25℃) | 180 | 77 | 167 | 167 | 5.25 |
| SY-GFM12024 › | 12V | 24Ah (10hrs/25℃) | 166 | 126 | 141 | 174 | 6.90 |
| SY-GFM12038 › | 12V | 38Ah (10hrs/25℃) | 197 | 165 | 174 | 174 | 11.00 |
| SY-GFM12055 › | 12V | 55Ah (10hrs/25℃) | 230 | 138 | 208 | 212 | 15.00 |
| SY-GFM12065 › | 12V | 65Ah (10hrs/25℃) | 350 | 166 | 58 | 19 | 18.00 |
| SY-GFM12100A › | 12V | 100Ah (10hrs/25℃) | 330 | 114 | 193 | 210 | 27.30 |
| SY-GFM12100B › | 12V | 100Ah (10hrs/25℃) | 407 | 173 | 208 | 238 | 28.50 |
| SY-GFM12120 › | 12V | 120Ah (10hrs/25℃) | 407 | 173 | 208 | 238 | 32.50 |
| SY-GFM12150 › | 12V | 150Ah (10hrs/25℃) | 485 | 172 | 240 | 240 | 40.00 |
| SY-GFM12200 › | 12V | 200Ah (10hrs/25℃) | 522 | 238 | 218 | 222 | 52.80 |
| SY-GFM12250 › | 12V | 300Ah (10hrs/25℃) | 521 | 269 | 220 | 224 | 66.80 |
Supports high-rate discharge up to 10C (10×rated capacity) for short-duration peak power demands (e.g., UPS backup during grid failure) and rapid recharge (80% capacity recovery in 4-6 hours at 0.3C charging current), 2x faster than gel batteries. The AGM fiberglass mat structure enhances ion conductivity, ensuring stable voltage output even under high-load conditions.
Vacuum-sealed ABS casing with one-way pressure relief valve eliminates electrolyte watering/topping-up and acid leakage, supporting vertical/horizontal/tilted mounting (±90°). The AGM mat absorbs 100% of sulfuric acid electrolyte, preventing stratification and extending lifespan by 30% compared to standard VRLA batteries in cyclic use.
