| Brand Name: | Soeteck |
| Model Number: | WF |
| MOQ: | 1 |
| Price: | To Be Negotiated |
| Delivery Time: | 4W |
| Payment Terms: | D/A |
Designed for both indoor and outdoor packaged installations, the Integrated Precision ACs for Data Center Cooling is a highly versatile thermal management solution. It leverages AgileBlue free cooling technology to achieve exceptional energy efficiency, effectively minimizing the PUE (Power Usage Effectiveness) of modern data centers, and is particularly ideal for containerized micro data centers and mini modular data centers in need of compact, reliable and sustainable cooling.
Equipped with advanced components including an inverter refrigerant pump, EC fan and smart controller, this system delivers precise cooling performance while reducing overall energy consumption. Its dual-mode operation (free cooling and mechanical cooling) ensures optimized performance across diverse ambient conditions, significantly boosting the system's EER (Energy Efficiency Ratio). With a modular, scalable design, full-year operational capability and intelligent monitoring, it provides a high-efficiency, low-maintenance and eco-friendly solution for the evolving demands of IT and telecommunication industries.
| Model No. | Cooling Capacity | Airflow Rate | Dimensions (W×D×H) | Weight | Pump Power |
|---|---|---|---|---|---|
| SY-WF-012 › | 12.5kW | 2400m³/h | 1000×650×2100mm | 285kg | 0.55kW |
| SY-WF-017 › | 17.5kW | 3500m³/h | 1000×650×2100mm | 320kg | 0.55kW |
| SY-WF-020 › | 21.2kW | 4000m³/h | 1000×650×2100mm | 355kg | 0.55kW |
Adopting AgileBlue free cooling technology, it achieves an impressive EER of up to 18.2, effectively lowering data center PUE. It eliminates the need for water circulation, which not only reduces environmental impact but also minimizes daily maintenance requirements and costs.
It supports two operational modes: Free Cooling Mode (EER 28.9) and Mechanical Cooling Mode (EER 3.9). The system automatically switches between modes based on ambient temperature, ensuring optimal cooling performance and energy savings in all weather conditions.
Equipped with a smart controller, it provides real-time monitoring and precise control of core components. It also offers remote debugging and monitoring capabilities, which greatly enhance operational reliability and reduce on-site maintenance workload.
Its compact footprint saves installation space, making it ideal for containerized data centers. The modular design enables easy future expansion for scalability. It also features an inverter refrigerant pump (for efficient liquid flow) and EC fan (for load-matched airflow), further optimizing energy consumption.
Focus on the core cooling demands of high-density data center deployments, where our full range of premium products leverages advanced technological advantages to reliably safeguard continuous, efficient, and stable operation.
7.5-300 kW
Designed for medium to large data centers, these units provide precise temperature and humidity regulation for the entire room. They utilize raised-floor or overhead delivery to ensure consistent airflow distribution and equipment stability.
5.6-90.1 kW
Positioned directly between server racks, this solution brings cooling closer to the heat source. It minimizes airflow paths to maximize efficiency, making it the ideal choice for managing hot spots and high-density computing clusters.
3.5-12.5 kW
An all-in-one solution integrated directly inside the server cabinet. This closed-loop system handles ultra-high thermal loads with maximum energy efficiency, isolating sensitive equipment from the outside room environment and noise.
1.0-4.0 kW
Compact and durable cooling designed for outdoor telecom cabinets, battery compartments, and industrial control panels. These units ensure reliable operation in harsh environments by strictly controlling internal temperatures and blocking contaminants.
Empowering next-generation infrastructure with superior thermal management for high-wattage computing demands.
